SYKW SERIES OF SERVO PRINTING FOLD GLUING BUNDLING LINKAGE LINE

FUNCTION,CHARACTERISTICS AND CONFIGURATION:

     Servo printing fold gluing bundling linkage line achieve CNC computer numerical control linkage operating system, each unit servo drive independently, accurate synchronization effect, speed is stable and reliable;Possess the order management function; Accomplish the carton printing, fold gluing, bundling in line with high efficiency production. Ordinary carton box printing, the highest design speed of up to 300 pcs/min; Coated paperboard printing can reach 80-120 pcs/min. Design concept according to advanced European technology, and through the European CE Ceritification, is the best choice for improving the production efficiency, reducing the manpower cost, automated corrugated box production, printing and forming process.

SYKW Series of servo printing fold gluing bundling linkage line -- Printing machine

1.Design security accord with the European CE safety standards and strive to humanized operation.

2.Adopt lead edge feeding paper technology with high precision.

3.Configuration with electrostatic brush and ion wind saber eliminate cardboard electrostatic .

4.Adopt America SUN company color master single doctor blade, the printing is more clear and perfect.

5.Phase adjustment adopt servo control to make sure rapid response and accurate adjustment.

6.Vacuum transfer paperboard system, wind power balance design makes running accuracy higher, feeder system can be flexible matching

 roller feeding and hot air drying system function, or achieve roller feeding and vacuum transfer double function, saving energy and reducing consumption.

7.Die-cutting anvil roller adopt single servo more independent drive, realizes speed difference compensation between rubber cushion and

template manufacturing error compensation

8.Die-cutting roller automatically eliminate the adjusting mechanism gap and die cutting vibration, improve the service life of the equipment.

9.Drying system, which has two kinds of infrared and ultraviolet ray, can respectively drying water-based ink, light oil and UV light oil. Temperature

 control system to ensure the safety of production. According to the board width automatically adjust scope of dry, to save energy.

SYKW Series of servo printing fold gluing bundling linkage line -- Prefeeder

1.Both side positioning baffle, can be adjusted according to different size of the cardboard, specification with electric adjustment.

2.Operation control is simple and convenient.

3.Supporting paperboard roller way can connect cardboard logistics delivery system.

4.Horizontal conveyor belt automatic control with hydraulic motor drive.

5.Traveling mechanism can connect with printing machine synchronously.

6.Automatic control paperboard transport with PLC.

SYKW Series of servo printing fold gluing bundling linkage line --fold gluing machine

1.Folding unit front part up and down belt synchronous drive, rear part adopt vacuum absorption feeding paperboard, transfer paperboard smoothly.

2.Both left and right folding belt adopts independent servo motor drive, it can adjust the  folding running speed difference accurately, eliminate the scissors error.

3.Cardboard transport adopt vacuum adsorption orientation.

4.Molding wheel auxiliary folding type, in the process of cardboard folding line to proceed the  second forming to stabilize the carton size.

5.Servo speed difference compensation to decrease the glue phenomenon not neat, servo control by batches to achieve partial stack at high speed.

6.Eject glue type to improve adhesion reliability and to avoid the glue pollution to carton and conveyor belt.

7.Automatically achieve 10 ~ 25 pcs automatic counting, partial bundling and transportation.
